• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Material	Steel
Number of Teeth	60
Product Type	Type "A" Plate Sprocket
Chain Pitch (in)	0.625 in
Outside Diameter (in)	12.301 in
Bore Type	Minimum Plain Bore
Pitch Diameter (in)	11.942077 in
Number of Strands/Width	1
Bore Diameter (in)	0.9375 in
Length Through Bore (in)	0.343 in
Hub Type	Type A
Maximum Bore (in)	2.5 in
Maximum Bore (mm)	63 mm
Minimum Bore (mm)	26 mm
Hardened Teeth	Non-Hardened Teeth
Number of Hubs	0

General Specifications

UPC	662289221745
Weight	10.74 LB
Packaged Length	14.10 IN
Packaged Width	13.60 IN
Packaged Height	1.40 IN
HTC	8483.90.1050
Country of Origin	China
