• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Number of Teeth	30
Product Type	Type "A" Plate Sprocket
Chain Pitch (in)	0.625 in
Material	Steel
Bore Type	Minimum Plain Bore
Outside Diameter (in)	6.321 in
Pitch Diameter (in)	5.979233 in
Number of Strands/Width	1
Bore Diameter (in)	0.71875 in
Hub Type	Type A
Length Through Bore (in)	0.343 in
Maximum Bore (in)	2.25 in
Maximum Bore (mm)	57 mm
Minimum Bore (mm)	20 mm
Number of Hubs	0
Hardened Teeth	With Hardened Teeth

General Specifications

UPC	662289141432
Weight	2.69 LB
Packaged Length	8.40 IN
Packaged Width	8.30 IN
Packaged Height	1.20 IN
HTC	8483.90.1050
Country of Origin	China
