• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Product Type	Type "A" Plate Sprocket
Chain Pitch (in)	0.625 in
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Number of Teeth	24
Material	Steel
Bore Type	Minimum Plain Bore
Outside Diameter (in)	5.122 in
Pitch Diameter (in)	4.788311 in
Bore Diameter (in)	0.71875 in
Number of Strands/Width	1
Length Through Bore (in)	0.343 in
Tooth Width (in)	0.343 in
Hub Type	Type A
Maximum Bore (in)	2.25 in
Maximum Bore (mm)	57 mm
Minimum Bore (mm)	20 mm
Hardened Teeth	With Hardened Teeth
Number of Hubs	0
Pitch Type	Single

General Specifications

UPC	662289251476
Weight	1.45 LB
Packaged Length	9.25 IN
Packaged Width	9.25 IN
Packaged Height	3.75 IN
HTC	8483.90.1050
Country of Origin	China
