• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Pitch (in)	0.625 in
Product Type	Type "A" Plate Sprocket
Material	Steel
Chain Used	No. 50, 5/8 in. Pitch ANSI Chain
Number of Teeth	21
Tooth Width (in)	0.343 in
Outside Diameter (in)	4.522 in
Bore Type	Minimum Plain Bore
Overall Length (in)	0.343 in
Length Through Bore (in)	0.343 in
Hub Type	Type A
Sprocket Material	Steel, Hardened Teeth
Chain Number	No. 50, 5/8 in. Pitch ANSI Chain
Pitch Diameter (in)	4.193441 in
Number of Strands/Width	1
Bore Diameter (in)	0.75 in
Maximum Bore (in)	2.25 in
Minimum Bore (mm)	20 mm
Maximum Bore (mm)	57 mm
Number of Hubs	0
Hardened Teeth	With Hardened Teeth

General Specifications

UPC	662289201419
Weight	1.10 LB
Packaged Length	9.25 IN
Packaged Width	9.25 IN
Packaged Height	3.75 IN
HTC	8483.90.1050
Country of Origin	China
