• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Max Bore (in)	1.5 in
Pitch Diameter (in)	4.783 in
Chain Pitch (in)	0.5 in
Chain Used	No. 41, 1/2 in. Pitch ANSI Chain
Min Bore (in)	0.375 in
Material	Steel
Number of Teeth	30
Product Type	Bushed Roller Chain Sprocket
Bushing Used	Split Taper
Outside Diameter (in)	5.057 in
Bore Type	Bushed Bore
Overall Length (in)	1.51225 in
Number of Strands/Width	1
Hub Diameter (in)	2.494 in
Maximum Bore (in)	1.5 in
Maximum Bore (mm)	38 mm
Minimum Bore (mm)	10 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289234486
Weight	1.54 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.13 IN
HTC	8483.90.1050
Country of Origin	China
