• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Used	No. 41, 1/2 in. Pitch ANSI Chain
Bushing Used	Split Taper
Pitch Diameter (in)	2.879 in
Min Bore (in)	0.375 in
Max Bore (in)	1.5 in
Chain Pitch (in)	0.5 in
Product Type	Bushed Roller Chain Sprocket
Number of Teeth	18
Material	Steel
Overall Length (in)	1.50625 in
Outside Diameter (in)	3.136 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	2.494 in
Maximum Bore (in)	1.5 in
Minimum Bore (mm)	10 mm
Maximum Bore (mm)	38 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289194384
Weight	0.80 LB
Packaged Length	3.56 IN
Packaged Width	3.56 IN
Packaged Height	1.44 IN
HTC	8483.90.1050
Country of Origin	China
