• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Material	Steel
Chain Pitch (in)	0.5 in
Product Type	Type "A" Plate Sprocket
Chain Used	No. 41, 1/2 in. Pitch ANSI Chain
Number of Teeth	40
Outside Diameter (in)	6.653 in
Bore Type	Minimum Plain Bore
Pitch Diameter (in)	6.372747 in
Bore Diameter (in)	0.71875 in
Number of Strands/Width	1
Hub Type	Type A
Length Through Bore (in)	0.226 in
Maximum Bore (in)	2.375 in
Minimum Bore (mm)	20 mm
Maximum Bore (mm)	60 mm
Number of Hubs	0
Hardened Teeth	Non-Hardened Teeth

General Specifications

UPC	662289200733
Weight	2.11 LB
Packaged Length	8.30 IN
Packaged Width	8.20 IN
Packaged Height	1.20 IN
HTC	8483.90.1050
Country of Origin	China
