• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Bushing Used	Split Taper
Number of Teeth	60
Product Type	Bushed Roller Chain Sprocket
Material	Steel
Chain Pitch (in)	0.5 in
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Min Bore (in)	0.75 in
Pitch Diameter (in)	9.554 in
Max Bore (in)	2.6875 in
Overall Length (in)	2.887375 in
Outside Diameter (in)	9.841 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	4.125 in
Maximum Bore (in)	2.6875 in
Minimum Bore (mm)	18 mm
Maximum Bore (mm)	65 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289225156
Weight	9.28 LB
Packaged Length	10.60 IN
Packaged Width	10.40 IN
Packaged Height	2.70 IN
HTC	8483.90.1050
Country of Origin	China
