• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Number of Teeth	54
Pitch Diameter (in)	8.599 in
Max Bore (in)	1.75 in
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Material	Steel
Min Bore (in)	0.5 in
Bushing Used	Split Taper
Product Type	Bushed Roller Chain Sprocket
Chain Pitch (in)	0.5 in
Outside Diameter (in)	8.885 in
Bore Type	Bushed Bore
Overall Length (in)	2.221225 in
Number of Strands/Width	1
Hub Diameter (in)	3 in
Maximum Bore (in)	1.75 in
Maximum Bore (mm)	42 mm
Minimum Bore (mm)	14 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289145171
Weight	5.68 LB
Packaged Length	10.40 IN
Packaged Width	10.40 IN
Packaged Height	1.70 IN
HTC	8483.90.1050
Country of Origin	China
