• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Min Bore (in)	0.5 in
Chain Pitch (in)	0.5 in
Product Type	Bushed Roller Chain Sprocket
Pitch Diameter (in)	7.963 in
Bushing Used	Split Taper
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Max Bore (in)	1.75 in
Number of Teeth	50
Material	Steel
Outside Diameter (in)	8.247 in
Overall Length (in)	2.221225 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	3 in
Maximum Bore (in)	1.75 in
Minimum Bore (mm)	14 mm
Maximum Bore (mm)	42 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289295142
Weight	5.03 LB
Packaged Length	10.60 IN
Packaged Width	10.20 IN
Packaged Height	1.40 IN
HTC	8483.90.1050
Country of Origin	China
