• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Min Bore (in)	0.5 in
Number of Teeth	48
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Max Bore (in)	1.75 in
Bushing Used	Split Taper
Chain Pitch (in)	0.5 in
Material	Steel, Hardened Teeth
Product Type	Bushed Roller Chain Sprocket
Pitch Diameter (in)	7.645 in
Bore Type	Bushed Bore
Overall Length (in)	2.221225 in
Outside Diameter (in)	7.929 in
Number of Strands/Width	1
Hub Diameter (in)	3 in
Maximum Bore (in)	1.75 in
Minimum Bore (mm)	14 mm
Maximum Bore (mm)	42 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289165117
Weight	4.61 LB
Packaged Length	8.10 IN
Packaged Width	7.90 IN
Packaged Height	1.80 IN
HTC	8483.90.1050
Country of Origin	China
