• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Number of Teeth	31
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Chain Pitch (in)	0.5 in
Max Bore (in)	1.75 in
Pitch Diameter (in)	4.942 in
Material	Steel
Min Bore (in)	0.5 in
Product Type	Bushed Roller Chain Sprocket
Bushing Used	Split Taper
Hub Diameter (in)	3 in
Bore Type	Bushed Bore
Overall Length (in)	2.221225 in
Hub Type	Bushed
Sprocket Material	Steel, Hardened Teeth
Outside Diameter (in)	5.217 in
Length Through Bore (in)	1.9375 in
Tooth Width (in)	0.284 in
Number of Strands/Width	1
Maximum Bore (in)	1.75 in
Maximum Bore (mm)	42 mm
Minimum Bore (mm)	14 mm
Pitch Type	Single
Number of Hubs	1
Min Bushing Bore (in)	0.5 in
Max Bushing Bore (in)	1.75 in

General Specifications

UPC	662289284986
Weight	2.48 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.31 IN
HTC	8483.90.1050
Country of Origin	China
