• When you think Sprockets - Think Browning
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.
• Maximum Bore Shown will accommodate standard keyways and setscrews over keyway. Slightly larger bores are possible with no keyway, shallow keyway or setscrew at angle to keyway.
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.

Technical Specifications

Product Type	Type "B" Minimum Bore Sprocket
Material	Steel
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Number of Teeth	14
Chain Pitch (in)	0.5 in
Bore Type	Minimum Plain Bore
Max Bore (in)	1.125 in
Outside Diameter (in)	2.49 in
Pitch Diameter (in)	2.247 in
Bore Diameter (in)	0.5 in
Number of Strands/Width	1
Hub Diameter (in)	1.6875 in
Hub Type	Type B
Length Through Bore (in)	0.875 in
Maximum Bore (in)	1.25 in
Minimum Bore (mm)	13 mm
Maximum Bore (mm)	31 mm
Hub Projection (in)	0.59375 in
Number of Hubs	1

General Specifications

UPC	662289249152
Weight	0.64 LB
Packaged Length	2.90 IN
Packaged Width	2.80 IN
Packaged Height	1.30 IN
HTC	8483.90.1050
Country of Origin	China
