• When you think Sprockets - Think Browning
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Number of Teeth	48
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Material	Steel
Product Type	Type "A" Plate Sprocket
Chain Pitch (in)	0.5 in
Outside Diameter (in)	7.929 in
Bore Type	Minimum Plain Bore
Pitch Diameter (in)	7.644894 in
Bore Diameter (in)	0.71875 in
Number of Strands/Width	1
Length Through Bore (in)	0.284 in
Hub Type	Type A
Maximum Bore (in)	2.375 in
Minimum Bore (mm)	16 mm
Maximum Bore (mm)	60 mm
Number of Hubs	0
Hardened Teeth	With Hardened Teeth

General Specifications

UPC	662289211159
Weight	3.69 LB
Packaged Length	8.80 IN
Packaged Width	8.80 IN
Packaged Height	1.30 IN
HTC	8483.90.1050
Country of Origin	China
