• When you think Sprockets - Think Browning
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Product Type	Type "A" Plate Sprocket
Material	Steel
Chain Pitch (in)	0.5 in
Chain Used	No. 40, 1/2 in. Pitch ANSI Chain
Number of Teeth	120
Bore Type	Minimum Plain Bore
Outside Diameter (in)	19.394 in
Pitch Diameter (in)	19.100775 in
Number of Strands/Width	1
Bore Diameter (in)	0.9375 in
Length Through Bore (in)	0.284 in
Hub Type	Type A
Maximum Bore (in)	0.75 in
Minimum Bore (mm)	0 mm
Maximum Bore (mm)	0 mm
Number of Hubs	0
Hardened Teeth	Non-Hardened Teeth

General Specifications

UPC	662289448326
Weight	23.00 LB
Packaged Length	0.28 IN
Packaged Width	19.39 IN
Packaged Height	19.39 IN
HTC	8483.90.1050
Country of Origin	China
