• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Pitch Diameter (in)	5.376 in
Bushing Used	Split Taper
Chain Used	No. 35, 3/8 in. Pitch ANSI Chain
Number of Teeth	45
Chain Pitch (in)	0.375 in
Max Bore (in)	1.5 in
Product Type	Bushed Roller Chain Sprocket
Min Bore (in)	0.375 in
Material	Steel
Bore Type	Bushed Bore
Overall Length (in)	1.51225 in
Outside Diameter (in)	5.588 in
Number of Strands/Width	1
Hub Diameter (in)	2.494 in
Maximum Bore (in)	1.5 in
Minimum Bore (mm)	10 mm
Maximum Bore (mm)	38 mm
Number of Hubs	1
Pitch Type	Single

General Specifications

UPC	662289214136
Weight	1.62 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.13 IN
HTC	8483.90.1050
Country of Origin	China
