• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Pitch Diameter (in)	2.992 in
Chain Used	No. 35, 3/8 in. Pitch ANSI Chain
Material	Steel
Min Bore (in)	0.375 in
Product Type	Bushed Roller Chain Sprocket
Chain Pitch (in)	0.375 in
Bushing Used	Split Taper
Max Bore (in)	1.5 in
Number of Teeth	25
Overall Length (in)	1.51225 in
Bore Type	Bushed Bore
Outside Diameter (in)	3.193 in
Number of Strands/Width	1
Hub Diameter (in)	2.494 in
Tooth Width (in)	0.168 in
Length Through Bore (in)	1.25 in
Maximum Bore (in)	1.5 in
Maximum Bore (mm)	38 mm
Minimum Bore (mm)	10 mm
Number of Hubs	1
Pitch Type	Single
Hardened Teeth	Yes
Hub Projection (in)	1.156 in
Overall Width (in)	1.5 in

General Specifications

UPC	662289274062
Weight	0.84 LB
Packaged Length	3.56 IN
Packaged Width	3.56 IN
Packaged Height	1.44 IN
HTC	8483.90.1050
Country of Origin	China
