• When you think Sprockets - Think Browning
• Browning type A steel plate roller chain sprockets are offered in single pitch range of 25-200

Technical Specifications

Chain Pitch (in)	0.375 in
Product Type	Type "A" Plate Sprocket
Chain Used	No. 35, 3/8 in. Pitch ANSI Chain
Material	Steel
Number of Teeth	35
Sprocket Material	Steel, Hardened Teeth
Bore Type	Minimum Plain Bore
Outside Diameter (in)	4.392 in
Length Through Bore (in)	0.169 in
Tooth Width (in)	0.168 in
Overall Length (in)	0.168 in
Hub Type	Type A
Chain Number	No. 35, 3/8 in. Pitch ANSI Chain
Pitch Diameter (in)	4.183433 in
Bore Diameter (in)	0.625 in
Number of Strands/Width	1
Maximum Bore (in)	1.625 in
Maximum Bore (mm)	41 mm
Minimum Bore (mm)	13 mm
Number of Hubs	0
Hardened Teeth	With Hardened Teeth

General Specifications

UPC	662289300549
Weight	0.66 LB
Packaged Length	9.25 IN
Packaged Width	9.25 IN
Packaged Height	3.75 IN
HTC	8483.90.1050
Country of Origin	China
