• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.
• Maximum Bore Shown will accommodate standard keyways and setscrews over keyway. Slightly larger bores are possible with no keyway, shallow keyway or setscrew at angle to keyway.
• Made with Minimum bore, no keyseat or setscrew. This can be bored to size with keyseat and setscrew for a reasonable extra charge.

Technical Specifications

Chain Pitch (in)	0.25 in
Product Type	Type "B" Minimum Bore Sprocket
Number of Teeth	12
Material	Steel
Chain Used	No. 25, 1/4 in. Pitch ANSI Chain
Bore Type	Minimum Plain Bore
Max Bore (in)	0.375 in
Outside Diameter (in)	1.08 in
Pitch Diameter (in)	0.966 in
Bore Diameter (in)	0.25 in
Number of Strands/Width	1
Length Through Bore (in)	0.5 in
Hub Type	Type B
Hub Diameter (in)	0.625 in
Hub Projection (in)	0.390625 in
Number of Hubs	1

General Specifications

UPC	662289138258
Weight	0.07 LB
Packaged Length	2.30 IN
Packaged Width	2.20 IN
Packaged Height	0.90 IN
HTC	8483.90.1050
Country of Origin	China
