• This Product has the Browning Exclusive Twice the Life Guarantee
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Bushing Used	Split Taper
Min Bore (in)	0.5 in
Max Bore (in)	1.75 in
Chain Pitch (in)	1.5 in
Chain Used	No. 2060, 1-1/2 in. Extended Pitch Roller Chain
Product Type	Bushed Roller Chain Sprocket
Number of Teeth	19
Material	Steel
Pitch Diameter (in)	4.62 in
Tooth Width (in)	0.459 in
Sprocket Material	Steel
Length Through Bore (in)	1.9375 in
Outside Diameter (in)	4.94 in
Hub Diameter (in)	3 in
Overall Length (in)	2.142725 in
Hub Type	Bushed
Bore Type	Bushed Bore
Number of Strands/Width	1
Pitch Type	Double
Hardened Teeth	Yes
Number of Hubs	1
Max Bushing Bore (in)	1.75 in
Min Bushing Bore (in)	0.5 in

General Specifications

UPC	662289150809
Weight	2.66 LB
Packaged Length	5.56 IN
Packaged Width	5.56 IN
Packaged Height	1.13 IN
HTC	8483.90.1050
Country of Origin	China
