• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Material	Steel
Pitch Diameter (in)	21.503 in
Min Bore (in)	1.6875 in
Product Type	Bushed Roller Chain Sprocket
Max Bore (in)	4.25 in
Chain Pitch (in)	1.5 in
Number of Teeth	45
Chain Used	No. 120, 1-1/2 in. Pitch ANSI Chain
Bushing Used	Split Taper
Outside Diameter (in)	22.365 in
Overall Length (in)	4.8199 in
Bore Type	Bushed Bore
Number of Strands/Width	1
Hub Diameter (in)	6.365 in
Maximum Bore (in)	4.25 in
Minimum Bore (mm)	0 mm
Maximum Bore (mm)	0 mm
Number of Hubs	2
Pitch Type	Single

General Specifications

UPC	662289107834
Weight	103.80 LB
Packaged Length	22.35 IN
Packaged Width	22.35 IN
Packaged Height	4.75 IN
HTC	8483.90.1050
Country of Origin	China
