• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Bushing Used	Split Taper
Product Type	Bushed Roller Chain Sprocket
Pitch Diameter (in)	16.734 in
Chain Pitch (in)	1.5 in
Number of Teeth	35
Material	Steel
Chain Used	No. 120, 1-1/2 in. Pitch ANSI Chain
Min Bore (in)	1.375 in
Max Bore (in)	3.625 in
Bore Type	Bushed Bore
Overall Length (in)	5.14 in
Outside Diameter (in)	17.842 in
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.625 in
Maximum Bore (mm)	90 mm
Minimum Bore (mm)	35 mm
Pitch Type	Single
Number of Hubs	2

General Specifications

UPC	662289187843
Weight	65.20 LB
Packaged Length	17.57 IN
Packaged Width	17.57 IN
Packaged Height	5.16 IN
HTC	8483.90.1050
Country of Origin	China
