• Browning offers one of the largest selection of application shaft ready sprockets in the industry
• Easy Installation and removal
• Split Taper Bushing are available in popular Inch, Metric and Spline bore
• Hardened Teeth at No Extra Cost - Drive Sizes up to 30 teeth on 35 through 160 Chain

Technical Specifications

Chain Used	No. 100, 1-1/4 in. Pitch ANSI Chain
Number of Teeth	36
Pitch Diameter (in)	14.342 in
Bushing Used	Split Taper
Material	Steel
Min Bore (in)	1.125 in
Chain Pitch (in)	1.25 in
Product Type	Bushed Roller Chain Sprocket
Max Bore (in)	3.75 in
Bore Type	Bushed Bore
Overall Length (in)	3.219375 in
Outside Diameter (in)	15.038 in
Number of Strands/Width	1
Hub Diameter (in)	5.375 in
Maximum Bore (in)	3.75 in
Minimum Bore (mm)	28 mm
Maximum Bore (mm)	95 mm
Pitch Type	Single
Number of Hubs	1

General Specifications

UPC	662289287468
Weight	33.93 LB
Packaged Length	15.10 IN
Packaged Width	15.20 IN
Packaged Height	2.50 IN
HTC	8483.90.1050
Country of Origin	China
