• Ram extruded ultra low friction dry lubricated UHMW-PE (NS) with 304 stainless steel sheath.
• Nolu-S is a proprietary blend of UHMW-PE and solid lubricants.
• Maintains good wear characteristics while significantly reducing coeffiecients of friction compared to standard UHMW.
• Unique self lubricating properties make it ideal for applications requiring reduced friction, noise reduction, and higher dry running speeds.
• Extends life of mating surfaces
• Reduces energy and water consumption
• Reduces conveyed product scratches and damages
• High wear resistance and impact strength
• Minimizes product pulsation on conveyors
• FDA and USDA complaint material.

Technical Specifications

Sheath Material	Stainless Steel
Max Temp (°F)	140 °F
Width (mm)	25.4 mm
Product Group	Guide RAILs
Product Line	Guide Products
Product Type	Conical Guides
Profile	Tee Guide Rail
Length (in)	240 in
Height (mm)	20.1 mm
Height (in)	0.79 in
Minimum Bend Radius	4
Width (in)	1 in
Measurement System	Imperial
Material	Nolu-S
Sheath Thickness (in)	0.078 in
Color	Grey
Dynamic Coefficient of Friction	0.09
Density UHMW (lb/in³)	0.034
UHMW Tensile Strength (psi)	4,000 - 5,500 psi
Density Stainless Steel (lb/in³)	0.283
Steel Gauge (ga)	14
Rail Type	Solid - Self Lubricating
Steel Tensile Strength (psi)	70,000 psi
FDA Compliant	Yes

General Specifications

UPC	787405521247
Weight	0.45 LB
Packaged Length	240.00 IN
Packaged Width	1.00 IN
Packaged Height	0.79 IN
HTC	8431.39.0010
Country of Origin	Mexico
