• Ram extruded UHMW-PE.
• Ultra high molecular weight material can be used in a variety of applications.
• Low friction characteristics of UHMW allow chains/belts and containers to move at high speed with minimum drag and noise as well as minimum container damage.
• Low friction
• High wear resistance
• FDA and USDA complaint material.
• 304 stainless steel sheath.

Technical Specifications

Max Temp (°F)	180 °F
Sheath Material	Stainless Steel
Width (in)	0.75 in
Measurement System	Imperial
Height (mm)	21.1 mm
Profile	Tee Guide Rail
Length (in)	72 in
Sheath Thickness (in)	0.078 in
Height (in)	0.83 in
Product Group	Guide RAILs
Product Type	Conical Guides
Material	UHMW-PE
Width (mm)	19.1 mm
Product Line	Guide Products
Color	White
Minimum Bend Radius	4
Density UHMW (lb/in³)	0.034
Rail Type	Standard
UHMW Tensile Strength (psi)	4,000 - 5,500 psi
Steel Gauge (ga)	14
Density Stainless Steel (lb/in³)	0.283
Steel Tensile Strength (psi)	70,000 psi
Dynamic Coefficient of Friction	0.09
FDA Compliant	Yes

General Specifications

UPC	787405475052
Weight	0.49 LB
Packaged Width	0.75 IN
Packaged Height	0.83 IN
HTC	8431.39.0010
Country of Origin	Mexico
