• Ram extruded UHMW-PE with static dissipating additives (SD).
• Ultra high molecular weight material can be used in a variety of applications.
• Low friction characteristics of UHMW allow chains/belts and containers to move at high speed with minimum drag and noise as well as minimum container damage.
• Low friction
• High wear resistance
• Static dissipating additives
• FDA and USDA complaint material.
• 304 stainless steel sheath

Technical Specifications

Sheath Material	Stainless Steel
Max Temp (°F)	180 °F
Length (in)	120 in
Width (in)	1.25 in
Sheath Thickness (in)	0.078 in
Color	Black
Product Type	Conical Guides
Material	Nolu-SD
Measurement System	Imperial
Width (mm)	31.8 mm
Minimum Bend Radius	4
Product Line	Guide Products
Height (mm)	21.1 mm
Height (in)	0.83 in
Profile	Tee Guide Rail
Product Group	Guide RAILs
Density UHMW (lb/in³)	0.034
UHMW Tensile Strength (psi)	4,000 - 5,500 psi
Dynamic Coefficient of Friction	0.09
Steel Tensile Strength (psi)	70,000 psi
Density Stainless Steel (lb/in³)	0.283
Steel Gauge (ga)	14
Rail Type	Standard - Static Dissipating
FDA Compliant	Yes

General Specifications

UPC	787405519886
Weight	0.57 LB
Packaged Length	12.00 IN
Packaged Width	1.25 IN
Packaged Height	0.83 IN
HTC	8431.39.0010
Country of Origin	Mexico
