• Threaded tube end for use with System Plast adjustable levelers.
• No welding, drilling, or tapping.
• Reinforced polyamide with brass insert.

Technical Specifications

Material	Reinforced polyamide with brass threaded insert
Thread (in)	1/2-13 in
Face Width / Diameter (in)	1.97 in
Face Width / Diameter (mm)	50 mm
Insert Width / Diameter (mm)	47 mm
Insert Depth (in)	1.55 in
Insert Depth (mm)	39 mm
Insert Width / Diameter (in)	1.87 in
Type	Square Tube Ends
Tube Size (sq) x Wall Thickness (in)	0.065 in
Height (in)	1.96 in
Measurement System	Imperial
Product Line	Conveying Components
Vertical Tube/Pipe Size (in)	2 Sq. Tube in
Component Series	VG-555
Product Group	Frame and Structure Components
Product Type	Tube End (Square)
Height (mm)	50 mm
Base Diameter (in)	0 in
Static Load (lb)	1,000 lb

General Specifications

UPC	787405256439
Weight	0.22 LB
Packaged Length	5.70 IN
Packaged Width	11.25 IN
Packaged Height	2.50 IN
HTC	8431.39.0010
Country of Origin	Mexico
