• Reinforced polyamide base, stainless steel stem.
• Heavy duty machinery support with adjusting nut welded to stem.

Technical Specifications

Duty Type	Heavy Duty
Vibration PAD	VG-514 / VG-514N
Leveler Type	Support Leveler
Deflection Angle	±2°
Type	520
Base Height with Pad (in)	0.89 in
Stem Material	Stainless Steel
Number of Lag Holes	2
Measurement System	Imperial
Product Line	Conveying Components
Base Diameter (in)	4.84 in
Spindle Length (in)	4.89 in
Material	POLYAMIDE
Base Height (in)	0.67 in
Product Group	Levelers
Wrench Height (in)	2.61 in
Component Series	VG-520
Lag Hole Center Distance (in)	3.88 in
Lag Hole Diameter (in)	0.52 in
Length (in)	7.48 in
Thread (in)	1-8 in
Product Type	Leveler (Polyamide Base)
Application	Machinery Support with adjusting nut welded to stem.
Leveler Operating Type	Adjustable
Max Recommended Static Load (lb)	7,000 lb

General Specifications

UPC	787405248939
Weight	1.73 LB
