• Reinforced polyamide base, stainless steel stem.
• Medium duty articulating leveler for conveyor and machinery support with two lag holes for anchoring to floor.

Technical Specifications

Stem Thread	M16
Vibration PAD	VG-512
Leveler Type	Articulating
Base Height with Pad (in)	0.83 in
Length (in)	4.52 in
Thread (mm)	M16 mm
Product Line	Conveying Components
Number of Lag Holes	2
Component Series	VG-511
Lag Hole Center Distance (in)	2.92 in
Spindle Length (in)	2.92 in
Lag Hole Diameter (in)	0.48 in
Base Diameter (in)	4 in
Product Type	Leveler (Polyamide Base)
Product Group	Levelers
Stem Material	Stainless Steel
Material	POLYAMIDE
Measurement System	Universal
Base Height (in)	0.73 in
Application	Conveyor and machinery support.
Misalignment Angle	±15°
Static Load (lb)	2,600 lb

General Specifications

UPC	787405245549
Weight	0.52 LB
Packaged Length	4.00 IN
Packaged Width	3.95 IN
Packaged Height	6.35 IN
