• Reinforced polyamide base, stainless steel stem.
• Light duty articulating leveler for conveyor and machinery support.

Technical Specifications

Stem Thread	1/2-13
Leveler Type	Articulating
Vibration PAD	VG-504
Length (in)	4.54 in
Base Height (in)	0.9 in
Product Line	Conveying Components
Product Type	Leveler (Polyamide Base)
Stem Material	Stainless Steel
Material	POLYAMIDE
Product Group	Levelers
Base Diameter (in)	2.38 in
Spindle Length (in)	2.64 in
Thread (in)	1/2-13 in
Measurement System	Imperial
Base Height with Pad (in)	0.97 in
Component Series	VG-501
Application	Conveyor and machinery support.
Misalignment Angle	±15°
Static Load (lb)	2,000 lb

General Specifications

UPC	787405238817
Weight	0.30 LB
Packaged Length	6.40 IN
Packaged Width	2.80 IN
Packaged Height	2.55 IN
