• Tube connecting joints.
• Reinforced polyamide material.
• Stainless steel screws and nuts.

Technical Specifications

Type	Tee Leg Tie
Material	POLYAMIDE
Overall Length (mm)	134 mm
Width (mm)	68 mm
Vertical Member (in)	1-1/4 pipe in
Height (mm)	86 mm
Horizontal Member (in)	1-1/4 pipe in
Product Type	Tee Leg Tie
Vertical Tube/Pipe Size (in)	1-1/4" Pipe in
Distance to Centerline (mm)	45 mm
Component Series	VG-3110
Product Group	Frame and Structure Components
Horizontal Tube Depth (mm)	60 mm
Product Line	Conveying Components
Horizontal Tube/Pipe Size (in)	1-1/4" Pipe in
Measurement System	Universal
Vertical Tube Diameter (mm)	42.2 mm
Horizontal Tube Diameter (mm)	42.2 mm
Max Recommended Tightening Torque (Kg)	1.5 kg

General Specifications

UPC	787405118904
Weight	0.88 LB
Packaged Length	2.68 IN
Packaged Width	3.39 IN
Packaged Height	5.28 IN
HTC	8431.39.0010
Country of Origin	Germany
