• Heavy duty clip for supporting guide rail.
• Two piece compression style for easy assembly and adjustment.
• Works with brackets, support beams, and adjusting rods.
• Stainless steel, 13 gauge.
• Hardware not included.

Technical Specifications

Duty Type	Heavy
Series	VG-018
Material	Stainless Steel
Fastener	5/16
Width (in)	0.85 in
Thread (in)	5/16 in
Component Series	VG-018
Height (in)	0.85 in
Measurement System	Imperial
Product Type	Rail Clamp (Single)
Length (in)	1 in
Product Line	Conveying Components
Bolt Length (in)	1.25 in
Product Group	Side Guide Solutions
Recommended Torque (N-m)	23 N·m
Recommended Torque (ft-lb)	17 ft/lbs

General Specifications

UPC	787405035652
Weight	0.08 LB
Packaged Length	5.30 IN
Packaged Width	5.25 IN
Packaged Height	1.85 IN
