• Easy head to tail transfer
• Ultra low friction
• Low noise beads
• Clean design
• Back-to-Back and end-to-end modularity
• Quick and easy assembly
• Mounting hardware included
• Acetal thermoplastic resin frame
• Blue acetal multi-rollers, suitable for irregular shaped products
• Stainless steel pins and hardware

Technical Specifications

Bolt Center Distance (mm)	80 mm
Length (mm)	115 mm
Width (in)	1.95 in
Width (mm)	50 mm
Roller Type	Standard
Bolt Effective Length (mm)	11.5 mm
Bolt Effective Length (in)	0.45 in
Bolt Center Distance (in)	3.15 in
Length (in)	4.53 in
Height (mm)	20 mm
Height (in)	0.79 in
Product Group	Miscellaneous
Component Series	TME-450
Material	ACETAL
Product Type	Roller Transfer Plate
Product Line	Conveying Components
Thread (mm)	M6 mm
Measurement System	Metric

General Specifications

UPC	787405125612
Weight	0.25 LB
Packaged Length	4.10 IN
Packaged Width	6.25 IN
Packaged Height	1.40 IN
HTC	8431.39.0010
Country of Origin	Germany
