• Easy head to tail transfer
• Ultra low friction
• Low noise beads
• Clean design
• Back-to-Back and end-to-end modularity
• Quick and easy assembly
• Mounting hardware included
• Acetal thermoplastic resin frame
• Red thermoplastic resin rollers with noise reducing characteristics
• Stainless steel pins and hardware

Technical Specifications

Roller Type	SR
Width (in)	1.47 in
Length (mm)	115 mm
Bolt Center Distance (mm)	80 mm
Bolt Effective Length (mm)	11.5 mm
Height (in)	0.79 in
Bolt Center Distance (in)	3.15 in
Bolt Effective Length (in)	0.45 in
Height (mm)	20 mm
Length (in)	4.53 in
Width (mm)	37 mm
Material	ACETAL
Component Series	TME-450
Product Line	Conveying Components
Product Type	Roller Transfer Plate
Product Group	Miscellaneous
Measurement System	Metric
Thread (mm)	M6 mm

General Specifications

UPC	787405572423
Weight	0.61 LB
Packaged Length	5.45 IN
Packaged Width	5.30 IN
Packaged Height	1.60 IN
HTC	8431.39.0010
Country of Origin	Germany
