• Austenitic stainless steel material.
• High corrosion and acid resistance material

Technical Specifications

Series	TableTop 815 Series Chain
Flight Thickness (in)	0.12 in
Product Group	Chain
Product Type	Straight Running
Product Line	Conveying Chains and Belts
Chain Material	SSA
Max Working Load (N)	5,300 N
Chain Width (in)	3.5 in
Flight Thickness (mm)	3.1 mm
Chain Width Measurement System	Imperial
Surface Type	Solid Top
Chain Material Description	Austenitic Stainless Steel
Chain Width (mm)	88.9 mm
Weight (kg/m)	2.7 kg/m
Finish (μm)	0.3
Weight (lb/ft)	1.8 lb/ft
Max Working Load (lb)	1,190 lb
Rod/Pin Material	SPM
Chain Pitch (in)	1.5 in
Chain Number	815
Straight or Side-Flex	Straight Running
Chain Pitch (mm)	38.1 mm

General Specifications

UPC	726166147761
Weight	1.93 LB
Packaged Length	8.30 IN
Packaged Width	8.35 IN
Packaged Height	3.80 IN
HTC	7315.12.0080
Country of Origin	Germany
