• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	TableTop 880 Series Side-flexing Chain
Product Line	Conveying Chains and Belts
Product Type	Side-Flexing
Product Group	Chain
Flight Thickness (in)	0.16 in
Flight Thickness (mm)	4 mm
Weight (kg/m)	1 kg/m
Chain Pitch (mm)	38.1 mm
Chain Width Measurement System	Imperial
Weight (lb/ft)	0.7 lb/ft
Chain Number	880TAB
Straight or Side-Flex	Side-flexing
Breaking Load (lb)	1,200 lb
Chain Material	NGE
Rod/Pin Material	Austenitic steel
Chain Pitch (in)	1.5 in
Curve Retention Type	TAB
Surface Type	Solid Top
Chain Width (in)	3.3 in
Breaking Load (N)	5,400 N
Chain Width (mm)	83.82 mm
Chain Material Description	NG evo (Gray Blue)

General Specifications

UPC	726166519308
Weight	0.65 LB
Packaged Length	12.00 IN
Packaged Width	0.63 IN
HTC	3923.29.0000
Country of Origin	Germany
