• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	TableTop 880 Series Side-flexing Chain
Product Group	Chain
Flight Thickness (in)	0.16 in
Product Line	Conveying Chains and Belts
Product Type	Side-Flexing
Flight Thickness (mm)	4 mm
Chain Width (mm)	114.3 mm
Chain Material Description	NG evo (Gray Blue)
Chain Number	880M
Weight (kg/m)	1.2 kg/m
Chain Pitch (in)	1.5 in
Weight (lb/ft)	0.8 lb/ft
Breaking Load (N)	5,100 N
Surface Type	Solid Top
Chain Width (in)	4.5 in
Breaking Load (lb)	1,150 lb
Curve Retention Type	Magnetic
Chain Pitch (mm)	38.1 mm
Straight or Side-Flex	Side-flexing
Rod/Pin Material	SPM
Chain Material	NGE
Chain Width Measurement System	Imperial

General Specifications

UPC	726166519186
Weight	0.75 LB
Packaged Length	11.70 IN
Packaged Width	10.30 IN
Packaged Height	5.20 IN
HTC	3923.29.0000
Country of Origin	Germany
