• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	TableTop 880 Series Side-flexing Chain
Flight Thickness (in)	0.16 in
Product Type	Side-Flexing
Product Line	Conveying Chains and Belts
Product Group	Chain
Flight Thickness (mm)	4 mm
Weight (lb/ft)	0.7 lb/ft
Chain Width (in)	3.3 in
Breaking Load (N)	5,100 N
Chain Width (mm)	83.82 mm
Chain Width Measurement System	Imperial
Weight (kg/m)	1.1 kg/m
Straight or Side-Flex	Side-flexing
Chain Pitch (in)	1.5 in
Rod/Pin Material	SPM
Chain Material Description	NG evo (Gray Blue)
Curve Retention Type	Magnetic
Breaking Load (lb)	1,150 lb
Chain Pitch (mm)	38.1 mm
Surface Type	Solid Top
Chain Material	NGE
Chain Number	880M

General Specifications

UPC	726166518813
Weight	0.69 LB
Packaged Length	11.50 IN
Packaged Width	10.00 IN
Packaged Height	4.00 IN
HTC	3923.29.0000
Country of Origin	Mexico
