• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	TableTop 828 Series Chain
Flight Thickness (in)	0.15 in
Product Line	Conveying Chains and Belts
Product Group	Chain
Product Type	Straight Running
Flight Thickness (mm)	4 mm
Breaking Load (N)	5,400 N
Chain Material Description	NG evo (Gray Blue)
Breaking Load (lb)	1,200 lb
Rod/Pin Material	Austenitic steel
Chain Width (mm)	83.82 mm
Chain Material	NGE
Chain Number	828
Chain Pitch (mm)	38.1 mm
Chain Width Measurement System	Imperial
Weight (lb/ft)	0.8 lb/ft
Straight or Side-Flex	Straight Running
Chain Width (in)	3.3 in
Chain Pitch (in)	1.5 in
Weight (kg/m)	1.2 kg/m
Surface Type	Solid Top

General Specifications

UPC	726166518691
Weight	0.70 LB
Packaged Length	11.50 IN
Packaged Width	10.25 IN
Packaged Height	4.00 IN
