• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	TableTop 828 Series Chain
Product Type	Straight Running
Product Line	Conveying Chains and Belts
Flight Thickness (in)	0.15 in
Product Group	Chain
Flight Thickness (mm)	4 mm
Chain Width (in)	3.25 in
Breaking Load (lb)	1,200 lb
Surface Type	Solid Top
Weight (lb/ft)	0.7 lb/ft
Chain Material Description	NG evo (Gray Blue)
Chain Pitch (mm)	38.1 mm
Chain Width (mm)	82.55 mm
Chain Pitch (in)	1.5 in
Weight (kg/m)	1.1 kg/m
Breaking Load (N)	5,400 N
Chain Material	NGE
Chain Width Measurement System	Imperial
Rod/Pin Material	Austenitic steel
Chain Number	828
Straight or Side-Flex	Straight Running

General Specifications

UPC	726166518394
Weight	0.70 LB
Packaged Length	11.50 IN
Packaged Width	10.00 IN
Packaged Height	4.00 IN
HTC	3923.29.0000
Country of Origin	Mexico
