• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	TableTop 821 Series Chain
Product Group	Chain
Product Type	Straight Running
Product Line	Conveying Chains and Belts
Flight Thickness (in)	0.19 in
Flight Thickness (mm)	4.8 mm
Chain Material	NGE
Chain Width Measurement System	Imperial
Chain Number	821
Chain Pitch (in)	1.5 in
Chain Width (in)	7.5 in
Rod/Pin Material	Austenitic steel
Weight (kg/m)	2.6 kg/m
Surface Type	Solid Top
Chain Material Description	NG evo (Gray Blue)
Straight or Side-Flex	Straight Running
Weight (lb/ft)	1.7 lb/ft
Chain Width (mm)	190.5 mm
Chain Pitch (mm)	38.1 mm
Breaking Load (lb)	1,650 lb
Breaking Load (N)	7,500 N

General Specifications

UPC	726166518660
Weight	1.66 LB
Packaged Length	11.00 IN
Packaged Width	10.50 IN
Packaged Height	8.40 IN
HTC	3923.29.0000
Country of Origin	Mexico
