• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	TableTop 820 Series Chain
Product Type	Straight Running
Product Group	Chain
Product Line	Conveying Chains and Belts
Flight Thickness (in)	0.16 in
Flight Thickness (mm)	4.1 mm
Chain Pitch (in)	1.5 in
Breaking Load (lb)	1,000 lb
Surface Type	Solid Top
Chain Number	820
Chain Material	NGE
Rod/Pin Material	Austenitic steel
Straight or Side-Flex	Straight Running
Weight (lb/ft)	1 lb/ft
Weight (kg/m)	1.5 kg/m
Chain Width (in)	7.5 in
Chain Pitch (mm)	38.1 mm
Chain Width (mm)	190.5 mm
Chain Material Description	NG evo (Gray Blue)
Breaking Load (N)	4,500 N
Chain Width Measurement System	Imperial

General Specifications

UPC	726166518646
Weight	0.98 LB
Packaged Length	11.00 IN
Packaged Width	10.50 IN
Packaged Height	8.50 IN
