• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	TableTop 820 Series Chain
Product Group	Chain
Flight Thickness (in)	0.16 in
Product Type	Straight Running
Product Line	Conveying Chains and Belts
Flight Thickness (mm)	4.1 mm
Chain Material Description	NG evo (Gray Blue)
Chain Number	820
Chain Material	NGE
Surface Type	Solid Top
Chain Pitch (mm)	38.1 mm
Chain Pitch (in)	1.5 in
Straight or Side-Flex	Straight Running
Breaking Load (N)	4,500 N
Breaking Load (lb)	1,000 lb
Chain Width (in)	4 in
Chain Width Measurement System	Imperial
Rod/Pin Material	Austenitic steel
Weight (lb/ft)	0.7 lb/ft
Weight (kg/m)	1 kg/m
Chain Width (mm)	101.6 mm

General Specifications

UPC	726166518615
Weight	0.64 LB
Packaged Length	12.00 IN
Packaged Width	0.53 IN
