• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	2252
Product Line	Plastic Modular Chain and Belt
Product Type	Straight Running
Product Group	Modular Plastic Belts
Belt Thickness (in)	0.5 in
Max Load Capacity (N/m)	6,480 N·m
Chain Pitch (in)	1 in
Chain Material	NGE
Surface Type	Solid Top
Chain Pitch (mm)	25.4 mm
Positrack	None
Belt Thickness (mm)	12.7 mm
Max Load Capacity (lb/ft)	1,460 lb/ft
Straight or Side-Flex	Straight Running
Chain Width Measurement System	Imperial
Chain Width (mm)	190.5 mm
Chain Number	2252FT
Chain Material Description	NG evo (Gray Blue)
Chain Width (in)	7.5 in
Rod/Pin Material	PBT(White)

General Specifications

UPC	726166517748
Weight	1.64 LB
Packaged Length	8.70 IN
Packaged Width	9.10 IN
Packaged Height	8.25 IN
HTC	3923.29.0000
Country of Origin	Mexico
