• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Series	2252
Product Line	Plastic Modular Chain and Belt
Product Group	Modular Plastic Belts
Product Type	Straight Running
Belt Thickness (in)	0.5 in
Max Load Capacity (N/m)	34,200 N·m
Chain Width (mm)	304.8 mm
Straight or Side-Flex	Straight Running
Belt Thickness (mm)	12.7 mm
Surface Type	Solid Top
Positrack	None
Chain Pitch (in)	1 in
Chain Width Measurement System	Imperial
Chain Pitch (mm)	25.4 mm
Rod/Pin Material	POM Grey
Chain Material Description	NG evo (Gray Blue)
Chain Width (in)	12 in
Chain Material	NGE
Chain Number	2252FT
Max Load Capacity (lb/ft)	2,350 lb/ft

General Specifications

UPC	726166517540
Weight	1.80 LB
Packaged Length	12.00 IN
Packaged Width	12.00 IN
Packaged Height	0.50 IN
HTC	3923.29.0000
Country of Origin	Mexico
