• NG Evo (gray blue in color) conveyor components made from engineered plastic resin.
• Longest Life
• Lowest friction.
• Good chemical resistance.
• High abrasion resistance.
• Less dusting than acetal chains
• Meets the requirement for materials as stated by ECI035/2004 and FDA CFR21 norms for direct food contact.

Technical Specifications

Belt Thickness (in)	0.34 in
Series	MatTop 2250 Series Side-flexing Chain
Product Line	Conveying Chains and Belts
Product Group	Modular Plastic Belts
Product Type	Side-Flexing
Max Load Capacity (N/m)	2,000 N·m
Chain Material Description	NG evo (Gray Blue)
Chain Width Measurement System	Imperial
Chain Pitch (mm)	25.4 mm
Rod/Pin Material	Austenic Steel
Belt Thickness (mm)	8.7 mm
Chain Material	NGE
Straight or Side-Flex	Side-flexing
Chain Pitch (in)	1 in
Chain Width (mm)	83.8 mm
Max Load Capacity (lb/ft)	450 lb/ft
Curve Retention Type	TAB
Chain Number	2250FT-TAB
Surface Type	Solid Top
Chain Width (in)	3.3 in

General Specifications

UPC	726166519414
Weight	1.24 LB
Packaged Length	15.50 IN
Packaged Width	10.50 IN
Packaged Height	5.40 IN
HTC	3923.29.0000
Country of Origin	Germany
