• LF (brown in color) acetal material is commonly used in the market and offers an improved coefficient of friction and is suitable for use in high speed applications.
• Special austenitic stainless steel pins with higher tensile strength and improved surface hardness.

Technical Specifications

Series	TableTop 880 Series Side-flexing Chain
Product Group	Chain
Product Line	Conveying Chains and Belts
Flight Thickness (in)	0.16 in
Product Type	Side-Flexing
Flight Thickness (mm)	4 mm
Breaking Load (N)	6,000 N
Weight (lb/ft)	0.7 lb/ft
Chain Pitch (mm)	38.1 mm
Chain Material	LF
Straight or Side-Flex	Side-flexing
Chain Pitch (in)	1.5 in
Breaking Load (lb)	1,350 lb
Chain Width Measurement System	Imperial
Chain Material Description	Tan Low Friction
Chain Number	880B
Chain Width (mm)	114.3 mm
Chain Width (in)	4.5 in
Weight (kg/m)	1 kg/m
Rod/Pin Material	Austenitic steel
Surface Type	Solid Top
Curve Retention Type	Bevel

General Specifications

UPC	726166148492
Weight	0.70 LB
Packaged Length	12.00 IN
Packaged Width	4.50 IN
Packaged Height	0.80 IN
HTC	3923.29.0000
Country of Origin	Mexico
