• LF (brown in color) acetal material is commonly used in the market and offers an improved coefficient of friction and is suitable for use in high speed applications.
• Special austenitic stainless steel pins with higher tensile strength and improved surface hardness.

Technical Specifications

Series	TableTop 821 Series Chain
Product Line	Conveying Chains and Belts
Product Type	Straight Running
Flight Thickness (in)	0.19 in
Product Group	Chain
Flight Thickness (mm)	4.8 mm
Straight or Side-Flex	Straight Running
Breaking Load (lb)	1,830 lb
Chain Width (mm)	254 mm
Weight (kg/m)	3.1 kg/m
Chain Width (in)	10 in
Surface Type	Solid Top
Chain Width Measurement System	Imperial
Breaking Load (N)	8,300 N
Chain Number	821
Rod/Pin Material	Austenitic steel
Chain Pitch (mm)	38.1 mm
Chain Pitch (in)	1.5 in
Weight (lb/ft)	2.6 lb/ft
Chain Material	LF
Chain Material Description	Tan Low Friction

General Specifications

UPC	726166147983
Weight	2.11 LB
Packaged Length	12.90 IN
Packaged Width	10.90 IN
Packaged Height	10.60 IN
HTC	3923.29.0000
Country of Origin	Mexico
