• LF (brown in color) acetal material is commonly used in the market and offers an improved coefficient of friction and is suitable for use in high speed applications.
• Special austenitic stainless steel pins with higher tensile strength and improved surface hardness.

Technical Specifications

Series	TableTop 820 Series Chain
Flight Thickness (in)	0.16 in
Product Line	Conveying Chains and Belts
Product Type	Straight Running
Product Group	Chain
Flight Thickness (mm)	4.1 mm
Surface Type	Solid Top
Chain Width (mm)	88.9 mm
Chain Material Description	Tan Low Friction
Weight (kg/m)	0.9 kg/m
Weight (lb/ft)	0.6 lb/ft
Straight or Side-Flex	Straight Running
Chain Material	LF
Chain Width (in)	3.5 in
Breaking Load (N)	5,000 N
Chain Number	820
Chain Width Measurement System	Imperial
Chain Pitch (in)	1.5 in
Chain Pitch (mm)	38.1 mm
Rod/Pin Material	Austenitic steel
Breaking Load (lb)	1,030 lb

General Specifications

UPC	726166183530
Weight	0.60 LB
Packaged Length	11.40 IN
Packaged Width	10.30 IN
Packaged Height	4.30 IN
HTC	3923.29.0000
Country of Origin	Germany
