• LF (brown in color) acetal material is commonly used in the market and offers an improved coefficient of friction and is suitable for use in high speed applications.
• Special austenitic stainless steel pins with higher tensile strength and improved surface hardness.

Technical Specifications

Series	TableTop 820 Series Chain
Product Type	Straight Running
Product Line	Conveying Chains and Belts
Flight Thickness (in)	0.16 in
Product Group	Chain
Flight Thickness (mm)	4.1 mm
Breaking Load (lb)	1,030 lb
Chain Width (mm)	82.55 mm
Straight or Side-Flex	Straight Running
Surface Type	Solid Top
Chain Pitch (mm)	38.1 mm
Rod/Pin Material	Austenitic steel
Chain Pitch (in)	1.5 in
Chain Width Measurement System	Imperial
Weight (kg/m)	0.9 kg/m
Chain Material	LF
Breaking Load (N)	5,000 N
Chain Material Description	Tan Low Friction
Weight (lb/ft)	0.6 lb/ft
Chain Number	820
Chain Width (in)	3.25 in

General Specifications

UPC	726166147884
Weight	0.61 LB
Packaged Length	11.50 IN
Packaged Width	10.00 IN
Packaged Height	4.10 IN
HTC	3923.29.0000
Country of Origin	Mexico
